| 交流输入电压范围 |
85～132VAC/170～264VAC由开关选择 |
| AC input voltage range |
85～132VAC/170～264VAC selectable by switch |
| 直流可调范围 |
输出电压的±10% |
| DC adjustment range |
±10% of rated output voltage |
| 过载保护 |
105%～150%过电流限制,切断输出自动复位. |
| Over load up protection |
105%～150% hiccup mode, auto-recovery |
| 起动,上升,保持时间 |
|
| Setup, rise, hold up time |
200ms, 100ms, 30ms at full load and 230VAC |
| 耐压性 |
|
| Withstand voltage |
I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC for 1 minute |
| 工作温度,湿度 |
|
| Working temperature |
-10～60℃(refer to output derating curve) |
| 安全标准 |
|
| Safety standards |
design refer to UL1012 |
| EMC标准 |
|
| EMC standards |
design refer to FCC part 15 J |
